Date* MM slash DD slash YYYY Company* Point of Contact* First Last Email* Phone*Fax1. LOAD REQUIREMENTSMeasurement Capacity QuantityType of Loading Static Fatigue Impact Capacity Overload Requirements: 150% without zero shift (standard) 300% without structural damage (standard) Other Describe Bridge Loading Configuration: Single-Axis Bi-Axial, Two Axes at 90° Apart (variable wrap angle) Redundant (dual) Bridge 2. ENVIRONMENTAL REQUIREMENTS Indoor Outdor Submerged Pressure psiOperating Temperature ° F3. SHEAVE PIN CONFIGURATION AND LAYOUTAe: Width of Sheave Tol: Bc: Width of Clevis Cheeks Tol: Db: Diam. of Clevis/Sheave Bore Tol: Dp: Diam. of Clevis Pin Tol: Ec: Width of Clevis Tol: 4. DESIGN FEATURESSpecify Connector Type Connector Permanently Attached Cable Length Specify Connector/Cable Location (1-5) Load Direction Standard Sheave Load direction is into the keeper slot at 1/2 of the wrap angle. (see "Standard" load direction below.) Standard Other Describe 5. ELECTRICAL REQUIREMENTSPin Output: mv/V (standard) 4-20ma loop powered Other Describe 6. SPECIAL / INSTRUMENTATION / CLEARANCE REQUIREMENTSPlease enter any pertinent information below:CommentsThis field is for validation purposes and should be left unchanged. Δ
